FIBER OPTIC CABLE CONNECTING PIPE SYSTEM【FOPS】

Heat shrinkable polyolefin tubing system with a steel rod (ceramic rod for ribbon fiber) for mechanical protection and a hot fusion insert for sealing. This protector provides mechanical reinforcement at the joint point and maintains the optic transmission properties of the fiber optic cable
Features and Benefits
★Retains optic transmission properties of optical fiber.
★Reinforces and protects fiber optic splice.
★Clear sleeve for easy inspection and minimizing damage during installation.
★One piece design with hot fusion insert for sealing against moisture and other contaminants.
★Different colors of hot fusion insert for labeling and identification.
★Rohs compliant, halogen free environmentally friendly.
★Single fiber and ribbon fiber splice protector available		 Shrink physical properties
★Operating Temperature: -55℃ to 100℃
★Shrink Temperature: 120℃
Color selection
★Sleeve: Transparent
★Fusion insert : Transparent, Red, Blue, Green or other color
Product Code Cross References
★Raychem/Tyco: SMOUV
★DSG Canusa: CFSP
★Sumitomo: FPS-1

Technical Details

Test Item Test Method Typical Value
Tensile strength ASTM D2671 18MPa
Breakdown elongation ASTM D2671 700%
Density ASTM D2671 0.95g/cm3
Dielectric strength ASTM D2671 25KV/MM
Dielectric constant ASTM D2671 2.5
Longitudinal change ASTM D2671 ±5%

Product Selection
★Large Sleeve

Product
Code 		Heat Shrink Tube Fusion Tube Steel Rod Standard
package
(pcs/pack)
I.D. after
Recovery(mm) 		Length
(mm) 		I.D.
(mm) 		Length
(mm) 		I.D.
(mm) 		Length
(mm)
FOPS-61-L 3.0 61 1.3 61 1.5 55 100
FOPS-45-L 3.0 45 1.3 45 1.5 40 100
FOPS-23-L 3.0 23 1.3 23 1.5 18 100

★Standard Sleeve

Product
Code 		Heat Shrink Tube Fusion Tube Steel Rod Standard
package
(pcs/pack)
I.D. after
Recovery(mm) 		Length
(mm) 		I.D.
(mm) 		Length
(mm) 		I.D.
(mm) 		Length
(mm)
FOPS-61-ST 2.5 61 1.3 61 1.2 55 100
FOPS-45-ST 2.5 45 1.3 45 1.2 40 100
FOPS-40-ST 2.5 40 1.3 40 1.2 36 100
FOPS-30-ST 2.5 30 1.3 30 1.2 26 100
FOPS-25-ST 2.5 20 1.3 25 1.2 21 100

★Small Sleeve

Product
Code 		Heat Shrink Tube Fusion Tube Steel Rod Standard
package
(pcs/pack)
I.D. after
Recovery(mm) 		Length
(mm) 		I.D.
(mm) 		Length
(mm) 		I.D.
(mm) 		Length
(mm)
FOPS-60-SM1 2.4 60 1.3 60 1.0 58 100
FOPS-60-SM2 2.0 60 0.5 60 1.0 56 100
FOPS-40-SM1 2.0 40 0.5 40 1.0 36 100
FOPS-40-SM2 1.7 40 1.0 40 0.7 39 100
FOPS-45-SM 1.7 45 1.0 45 0.7 44 100
FOPS-50-SM 1.7 50 1.0 50 0.7 49 100

★Mini/Micro Sleeve

Product
Code 		Heat Shrink Tube Fusion Tube Steel Rod Standard
package
(pcs/pack)
I.D. after
Recovery(mm) 		Length
(mm) 		I.D.
(mm) 		Length
(mm) 		I.D.
(mm) 		Length
(mm)
FOPS-40-MIC 1.3 40 0.5 40 0.5 39 100
FOPS-25-MIC 1.3 25 0.5 25 0.5 24 100
FOPS-18-MIC 1.3 18 0.5 18 0.5 17 100
FOPS-15-MIC 1.3 15 0.5 15 0.5 14 100
FOPS-10-MIC 1.3 10 0.5 10 0.5 9 100

★Ribbon Fiber Product Dimension

Product
Code 		Heat Shrink Tube I.D. Fusion Tube Ceramic Rod Standard package
(mm) (mm) Width(mm) Height(mm) (pcs/pack)
FOPS-6R 40 2.9 3.8 1.65 50
FOPS-12R 40 4.1 5.1 2.10 50

Ordering
★Product Code★Quantity★Package
Thank you for your order and Write accurately
